Advantech EKI-2706E-1GFPI-BE
4FE 1GE 1G SFP Unmanaged Ind. PoE Switch W/T
- Supports 10/100/1000 Mbps Auto Negotiation (EKI-2706G).
- Supports jumbo frame transmission up to 9 kbytes.
- DIN-rail with IP30 metal mechanism.
- Redundant 24~28 VDC power input.
- 4 x IEEE 802.3 af/at PoE ports 1 x Gigabit Copper 1 Gigabit SFP ports.
4FE 1GE 1G SFP Unmanaged Ind. PoE Switch W/T
- Supports 10/100/1000 Mbps Auto Negotiation (EKI-2706G).
- Supports jumbo frame transmission up to 9 kbytes.
- DIN-rail with IP30 metal mechanism.
- Redundant 24~28 VDC power input.
- 4 x IEEE 802.3 af/at PoE ports 1 x Gigabit Copper 1 Gigabit SFP ports.
The EKI-2706 Series has 24VDC redundant power input and double protection: Power Polarity Reverse Protect and Overload Current Fuse. It has up to 4 IEEE 802.3 af/at PoE/PoE ports and a relay output for event alarms. It has an IP30 rating for dusty environments.
| Interface | Ports Number | 6 |
| Ethernet Communication | RJ-45 Port Connector Type | 5 x RJ-45 1 x SFP ports |
| RJ-45 Transmission Speed | 10/100 Mbps ; 10/100/1000 Mbps | |
| Power | Power Input (DC) | 24 ~ 48 VDC |
| Certification | Ethernet Standard | IEEE 802.1p, 802.3ad, 802.1x, 802.1D, 802.1s, 802.1w, 802.3af/at |
| Ethernet Communication | RJ-45 Transmission Distance | 100 m |
| PoE Information | PoE Port Number | 4 |
| Ethernet Communication | Fiber Transmission Distance | Up to 110 km |
| Switch Properties | MAC Table Size | 2K |
| Packet Buffer Size | 1M bit | |
| Switch Fabric Speed | 4.8Gbps | |
| Jumbo Frame | 9,216 bytes | |
| Mechanism | Dimensions (W x H x D) | 30 x 140 x 95 mm (1.18′ x 5.51′ x 3.74 in.) |
| IP Rating | IP30 | |
| Enclosure (Metal) | Metal | |
| Weight | 0.45 kg (1.0 lb) | |
| Mounting | DIN-rail, Wall | |
| Environment | Temperature (Operating Range) | -40 ~ 75°C |
| Temperature (Storage Range) | -40 ~ 85°C | |
| Relative Humidity | 10~95% | |
| MTBF | Time | 1,697,086 hours |
| Method | Telcordia(Relax), GB | |
| Power | Power Operating Current | 1A @ 24 VDC |
| Power Consumption | Max 2W | |
| Power Connector Type | 6-pin removable screw terminal (power & relay) | |
| Certification | EMI | CE, FCC Class A |
| Safety | UL 60950-1 | |
| EMC | EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3) | |
| Shock | IEC 60068-2-27 | |
| Freefall | IEC 60068-2-32 | |
| Vibration | IEC 60068-2-6 | |
| Warranty | Warranty Period | 5 years |
